Rf amplifiers
LNA/Preamplifiers
LNA
Frequency Range: DC-3500 MHz
I/O impedance: 50 Ω
Gain: 18 dB
Noise figure: 3.5 dB
Operating voltage: +5 V
Operating current: 75 mA
Power output at 1dB compression (OP1dB): +18.5 dBm
Preamplificador 500 mW
Frequency Range: DC-3500 MHz
I/O impedance: 50 Ω
Gain: 18 dB
Noise figure: 3.5 dB
Operating voltage: +5 V
Operating current: 75 mA
Power output at 1dB compression (OP1dB): +18.5 dBm
Preamplificador 70 mW
Frequency Range: 400-4000 MHz
I/O impedance: 50 Ω
Gain: 14 dB
Operating voltage: +5 V
Operating current: 133 mA
Power output at 1dB compression (OP1dB): +27dBm
Power Amplifiers
2 Watt PA
Frequency Range: 1500-2800 MHz
I/O impedance: 50 Ω
Gain: 25 dB
Operating voltage: +5 V
Operating current: 400 mA
Power output at 1dB compression (OP1dB): +33 dBm
4 Watt PA
Frequency Range: DC-6000 MHz
I/O impedance: 50 Ω
Gain: 14 dB
Operating voltage: +28 V, -1.7 }v
Operating current: 75 mA
Power output at 1dB compression (OP1dB): +36 dBm
